Msata To SATA SSD/HDD Adapter Converter Card

Introduction

The MSAT2SAT3 mSATA to SATA adapter enables you to connect a standard SATA drive to an available mSATA port.

The adapter improves system capacity by enabling an mSATA port to host a larger SATA hard drive (tested up to 4TB). For guaranteed compatibility and performance the adapter is compliant with SATA I/II/III revisions, allowing for transfer speeds up to 6Gb per second.

The MSAT2SAT3 is backed by a StarTech.com 2-year warranty and free lifetime technical support.

The StarTech.com Advantage
- Improve system capacity by connecting a larger SATA hard drive to an mSATA host controller

Ports & interfaces

Host interface

mSATA

Output interface

SATA

SATA revision

3.0

Design

Internal

Y

Product colour

Green

Features

Data transfer rate (max)

6 Gbit/s

Operational conditions

Operating temperature (T-T)

5 - 50 °C

Storage temperature (T-T)

-25 - 70 °C

Operating relative humidity (H-H)

20 - 80%

Storage relative humidity (H-H)

15 - 90%

Technical details

Sustainability certificates

RoHS

Weight & dimensions

Width

30 mm

Depth

51 mm

Height

8 mm

Weight

4 g

Packaging data

User guide

Y

Package width

125 mm

Package depth

225 mm

Package height

10 mm

Package weight

15 g
