OPS PC module - PCM11-I5 - i5 1135G7 / 11300H - 8GB Ram - 256GB SSD - Win11 Pro

Introduction

SMART Open Pluggable Specification (OPS) PC modules provide a hassle-free Windows® 10 Pro solution based on 11th generation Intel® Core™ processors, and are designed specifically to work with SMART Board® interactive displays. Available in two standard configurations, all OPS PC modules in the PCM11 series are WHQL (Windows Hardware Quality Labs) certified and fully licensed with Windows 10 Pro out of the box. Install the OPS PC module in a SMART Board interactive display’s OPS slot to provide a complete 4K UHD Windows 10 solution at your fingertips, without the need for an external device or additional cables.

Install familiar Windows software applications, such as SMART Notebook® collaborative learning software, SMART TeamWorks™ visual collaboration software, and SMART Meeting Pro® software, and access the internet directly through your existing interactive display’s network connection. Upgrades and service for the OPS PC module are easy to perform without removing the interactive display from its mounting.

Processor

Processor manufacturer

Intel

Processor family

Intel® Core™ i5

Processor generation

11th gen Intel® Core™ i5

Processor model

i5-1135G7

Processor cores

4

Processor boost frequency

4.2 GHz

Processor cache

8 MB

Memory

Internal memory

8 GB

Internal memory type

DDR4-SDRAM

Memory layout (slots x size)

2 x 4 GB

Storage

Total storage capacity

256 GB

Storage media

SSD

Storage drive interface

M.2

SSD form factor

M.2

Graphics

On-board graphics card model

Intel Iris Xe Graphics

Maximum resolution

7680 x 4320 pixels

Network

Wi-Fi

Yes

Wi-Fi standards

Wi-Fi 6 (802.11ax)

Ethernet LAN

Yes

Cabling technology

10/100/1000Base-T(X)

Bluetooth

Yes

Bluetooth version

5.2

WLAN controller manufacturer

Intel

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

USB 2.0 ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

2

USB Type-C ports quantity

2

Headphone outputs

1

DC-in jack

Yes

HDMI ports quantity

2

Design

Product colour

Black

LED indicators

HDD, Power

Cable lock slot type

Kensington

Display

Display included

No

Software

Operating system installed

Windows 10 Pro

Trusted Platform Module (TPM)

Yes

Power

AC input voltage

12 - 19 V

Power consumption (max)

60 W

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

10 - 90%

Certificates

Certification

UL Recognized, FCC, ISED, CONEG Packaging, California Prop 65, CE, UKCA, REACH, RoHS, Battery, Packaging, POP, RCM Mark, WHQL

Weight & dimensions

Width

200 mm

Height

30 mm

Weight

910 g

Packaging data

Package width

270 mm

Package depth

220 mm

Package height

70 mm

Technical details

Harmonized System (HS) code

84713000
