Large Format Display - Pn-l2b-series - 86in

Introduction

Enjoy a more natural way of working

The BIG PAD L2B range of smart interactive displays combines genuine ‘4K reading and writing’ and an intuitive ‘Pen-on-Paper’ user experience with Zero Bonding and Sharp’s PrecisionTouch technology. The single USB-C connector makes it so simple to walk into a room, plug in your device and start working together straightaway. The L2B series also features an integrated Android PC with whiteboard, overlay writing mode and wireless screen sharing functionality as well as graded security to help enhance your productivity.

The BIG PAD L2B series is the perfect choice for busy office environments, boardrooms, meeting rooms and training sessions that require quick responsive operation and smart integrated collaboration tools. It encourages effective group teamwork, promotes idea sharing and helps people deliver great presentations and achieve better meeting outcomes.

Features

Display diagonal

2.18 m (86")

Display brightness

350 cd/m²

Display resolution

3840 x 2160 pixels

HD type

4K Ultra HD

Panel type

IPS

LED backlighting type

Direct-LED

Native aspect ratio

16:9

Contrast ratio (typical)

1200:1

Response time

8 ms

Touchscreen

Y

Touch technology

Multi-touch

Number of simultaneous touchpoints

20

Viewing angle, horizontal

178°

Viewing angle, vertical

178°

Screen glass thickness

3.4 mm

Haze rate

8%

Hardness

8H

Computer system

Operating system installed

Android 9

Built-in processor

Y

Processor architecture

ARM Cortex-A73

User memory

32 GB

RAM capacity

4 GB

Audio

Built-in speaker(s)

Y

Number of built-in speakers

2

Speaker power

20 W

Projector

Built-in projector

N

Network

Wi-Fi

Y

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

Wi-Fi standards

802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)

Bluetooth

Y

Bluetooth version

5.0

Ethernet LAN

Y

Ethernet LAN data rates

10,100 Mbit/s

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB 2.0 ports quantity

1

HDMI ports quantity

3

USB Type-C ports quantity

1

Ethernet LAN (RJ-45) ports

1

VGA (D-Sub) ports quantity

1

Headphone connectivity

3.5 mm

Audio output

1

RS-232 ports

1

Ergonomics

Product colour

Black

Certification

CE; FCC; RCM; REACH; RoHS; UL/C-UL

Power

Power consumption (max)

470 W

Power consumption (standby)

0.5 W

AC input voltage

100 - 240 V

AC input frequency

50/60 Hz

System requirements

Windows operating systems supported

Windows 10, Windows 11, Windows 8.1

Mac compatibility

Y

Linux operating systems supported

Y

Mobile operating systems supported

Android 9.0

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Operating relative humidity (H-H)

20 - 80%

Weight & dimensions

Width

1957 mm

Depth

85.7 mm

Height

1159.5 mm

Weight

62.5 kg

Packaging data

Package width

2112 mm

Package depth

280 mm

Package height

1283 mm

Package weight

84 kg

Packaging content

Manual

Y

Cables included

AC, HDMI, USB

Remote control included

Y

Batteries included

Y

Stylus included

Y

Number of stylus pens

2

Open Pluggable Specification (OPS) included

Y
