WAX620 Wireless Access Point Dual Band PoE Multi-Gig Wi-Fi 6 AX3600

Introduction

Get powerful and reliable WiFi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for the smaller business.

High-Performance Business WiFi
Faster and more reliable dual band WiFi 6 with 8 streams and up to 2.4Gbps in 5GHz band and 1.2Gbps in 2.4GHz band

Ideal for High Density Environments
Ultimate WiFi performance for schools, hotels, restaurants, and conference centers.

Greater Network Capacity
Enjoy 4x more connection capacity than your current WiFi and improved efficiency for longer battery life.

Seamless Wireless Mesh
Wire-free installation with other WAX620, WAX610, WAX610Y, WAC540, or WAC564 creates the perfect seamless business network.

Multi-Gigabit Speed
Includes a 2.5 Gbps Ethernet port with PoE for high speed wired network connectivity and easy wiring

Easy Setup
Set up, configure, and manage with NETGEAR Insight

Flexible Mounting
Easy to securely install on the wall of a suspended ceiling with the hardware included

Business-Level Security
WPA3 for the highest level of WiFi connection security

8 Wireless Networks (SSIDs)
Separate and secure networks for admin, guests, employees and IoT devices like cameras, locks and more

Separate VLANs
Keep admin, employee, visitor, HR, Finance department networks safely separated from each other

Features

2.4 GHz

Y

5 GHz

Y

Maximum data transfer rate

3600 Mbit/s

Maximum data transfer rate (2.4 GHz)

1200 Mbit/s

Maximum data transfer rate (5 GHz)

2400 Mbit/s

Ethernet LAN data rates

100,1000,2500 Mbit/s

Networking standards

IEEE 802.11ax,IEEE 802.11i,IEEE 802.3af,IEEE 802.3at

Auto MDI/MDI-X

Y

MIMO

Y

MIMO type

Multi User MIMO

Modulation

OFDM

Wi-Fi Multimedia (WMM)/(WME)

Y

VLAN support

Y

Security

Security algorithms

EAP-TLS,PEAP,SSL/TLS,TTLS,WPA,WPA2,WPA3

MAC address filtering

Y

Auto Wireless Distribution System (WDS)

Y

Management features

Web-based management

Y

Ports & interfaces

Ethernet LAN (RJ-45) ports

1

DC-in jack

Y

Power

Power over Ethernet (PoE)

Y

Output voltage

12 V

Output current

2.5 A

Design

Placement

Ceiling, Wall

Product colour

White

LED indicators

LAN, Power, WLAN

Antenna

Antenna type

Internal

Antenna gain level (max)

4.3 dBi

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Weight & dimensions

Width

205.7 mm

Depth

205.7 mm

Height

34.3 mm

Weight

783 g

Packaging data

Number of products included

1 pc(s)

Mounting kit

Y

Quick start guide

Y
