SSD - Dc600me - 960GB - SATA 3 - 2.5in - Aes 256-bit Encryption

Introduction

Kingston’s DC600M and DC600ME SSDs are fourth-generation data center SATA 3.0, 6Gbps SSDs utilising 3D TLC NAND intended for “mixed use” server workloads. Both are well suited for a wide variety of server applications and include on-board power loss protection via hold-up capacitors. DC600M and DC600ME are designed to protect data against unexpected power failure and to ensure the drive will successfully reinitialise on the next power-up of the system. Designed to deliver low latency and IO consistency for system integrators, hyperscale data centers and cloud service providers.

DC600ME features AES 256-bit encryption and supports TCG OPAL 2.0 security standards.

Capacities available from 480GB–7.68TB* to meet your data storage requirements.

Designed for data center environments
Optimised to meet the high demands of server RAID applications with low latency and IO consistency as the key design criteria.

Hardware-based PLP
Power loss capacitors to protect user data against unexpected power loss and enhance performance.

Delivers excellent quality of service (QoS)*
Optimised performance predictability to meet
service-level agreements (SLAs).

AES 256-bit Encryption with DC600ME
Protect sensitive data with support for AES 256-bit hardware-based encryption and TCG Opal 2.0 security standards with DC600ME.

Capacities up to 7.68TB
Upgrade and manage storage with capacities up to 7.68TB.*

Features

Security algorithms

256-bit AES

SSD capacity

960 GB

SSD form factor

2.5"

Interface

Serial ATA III

Memory type

3D TLC NAND

Component for

Server/workstation

Hardware encryption

Yes

Target workload

Mixed Use (MU)

Data transfer rate

6 Gbit/s

Read speed

560 MB/s

Write speed

530 MB/s

Random read (4KB)

94000 IOPS

Random write (4KB)

65000 IOPS

Read latency

130 µs

Write latency

70 µs

S.M.A.R.T. support

Yes

Hot-Plug support

Yes

H/W PLP function

Yes

Mean time between failures (MTBF)

2000000 h

TBW rating

1752

Use conditions

Server/Enterprise

Power

Power consumption (read)

1.6 W

Power consumption (write)

3.6 W

Power consumption (average)

1.45 W

Power consumption (idle)

1.3 W

Weight & dimensions

Width

69.8 mm

Depth

69.9 mm

Height

7 mm

Weight

69 g

Packaging data

Package width

129.5 mm

Package depth

9.14 mm

Package height

184.2 mm

Package weight

91.2 g

Package type

Hanging box

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-40 - 85 °C

Operating vibration

2.17 G

Non-operating vibration

20 G

Logistics data

Country of origin

China, Taiwan

Master (outer) case width

135.9 mm

Master (outer) case length

203.2 mm

Master (outer) case height

69.8 mm

Master (outer) case gross weight

989.98 g

Products per master (outer) case

10 pc(s)
