Hard Drive 120GB 2.5in Hs SATA Mlc Enterprise Value SSD

Introduction

New IBM 120 GB, 240 GB, 480 GB, and 800 GB solid-state drives (HDDs) are next-generation Enterprise Value SSDs for System x® that are engineered for greater performance and endurance in a cost-effective design and to support a broader set of workloads. These affordable, high performance SSDs support a broad range of data center application workloads; from read-intensive to mixed workloads of up to 70% read 30% write.

- All capacities are offered in 1.8-inch, 2.5-inch, and 3.5-inch options.
- 20nm MLC NAND flash technology delivers up to 65,000 4K random read IOPS and up to 35,000 4K random write IOPS.
- Sequential bandwidth ranges up to 440 MBps read and 375 MBps write.
- Endurance extends up to 2.4 DWPD for five years.
- Advanced power loss functionality features both data at rest protection and data in flight protection.
- Enterprise data path protection includes single-bit error detection and correction, as well as double-bit error detection.
- Rigorous testing through the ServerProven® program instills confidence that your storage subsystem is compatible and will function reliably.

Features

SSD form factor

2.5"

SSD capacity

120 GB

Interface

Serial ATA III

Memory type

MLC

Data transfer rate

6 Gbit/s

Read speed

440 MB/s

Write speed

375 MB/s

Random read (4KB)

65000 IOPS

Random write (4KB)

35000 IOPS

Lithography

20 nm

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Operating relative humidity (H-H)

8 - 85%

Maximum operating altitude

3050 m

Weight & dimensions

Width

69.8 mm

Depth

100.5 mm

Height

7 mm

Weight

71.7 g

Other features

Internal

Y
