E5576-320 Mobile Wi-Fi Hotspot White

Design

Device type

Cellular wireless network equipment

Product colour

White

Housing material

Plastic

Mounting

Wall mounting

Market positioning

Portable

Reset button

Y

LED indicators

LTE, Status

Ethernet LAN features

Ethernet LAN

N

Ethernet LAN interface type

Not available

DHCP server

Y

Wireless LAN features

Wi-Fi

Y

Wi-Fi standards

802.11b,802.11g,Wi-Fi 4 (802.11n)

Mobile network

Data network

3G, 4G

3G standards

UMTS

4G standard

LTE-FDD

4G bands supported

700,800,900,1800,2100,2600 MHz

UMTS bands supported

900,2100 MHz

Number of SIM cards

1

Short Message Service (SMS)

Y

Ports & interfaces

USB port

Y

Security

Security algorithms

SSID,WEP,WPA,WPA2-PSK

Network address translation (NAT)

Y

IP address filtering

Y

DMZ support

Y

Performance

Windows operating systems supported

Windows 10,Windows 7,Windows 8,Windows 8.1

Mac operating systems supported

Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.9 Mavericks

Antenna

Antenna type

Internal

Power

Power source type

Battery

AC input voltage

100 - 240 V

Output voltage

5 V

Output current

1 A

Battery capacity

1500 mAh

Battery voltage

3.8 V

Operational conditions

Operating temperature (T-T)

0 - 35 °C

Storage temperature (T-T)

-20 - 60 °C

Operating relative humidity (H-H)

5 - 95%

Weight & dimensions

Width

100 mm

Depth

58 mm

Height

14 mm

Weight

71 g

Packaging data

Cables included

USB

Package width

112 mm

Package depth

74 mm

Package height

38 mm

Package weight

117 g
