SureColor Sc-t5200d - Color Printer - Inkjet - A0 - USB / Ethernet (c11cd40301a0)

Introduction

Ideal for graphics, CAD and GIS
The SureColor SC-T5200D is one of the SureColor SC-T series of high-speed, four-colour large-format printers, designed to produce a wide range of high-quality display graphics, CAD and GIS applications in design, commercial print, copy shop, architecture, building, engineering, retail and education environments.

Highly productive
To maximise productivity and flexibility, the SC-T5200D features double rolls with auto paper loading and auto switching between media, and high-speed printing - outputting an A1 print takes just 28 seconds.

Fast
The SureColor SC-T5200D features 1GB of RAM for ultra-fast image processing, and an optional 320GB HDD for job caching and recall. Optional PostScript support with dual 1.6GHz CPUs enables printing of large data-rich files quickly and directly from leading design and CAD programs.

High quality output
The combination of Epson's PrecisionCore TFP printheads and UltraChrome XD pigment ink delivers industry-leading output quality and precise, repeatable performance. UltraChrome XD pigment ink is smudge and water resistant and delivers deep blacks and crisp, dense lines - ideal for technical graphics - and the vibrant colours necessary for high-quality prints and posters, on coated and non-coated media - including board up to 1.5mm thick.

Printing

Colour

Y

Maximum resolution

2880 x 1440 DPI

Page description languages

ESC/P-R,HP-GL/2,HP-RTL

Printing colours

Cyan, Magenta, Matte black, Photo black, Yellow

Paper handling

Maximum print size

A0 (841 x 1189 mm)

ISO A-series sizes (A0...A9)

A0,A1,A2,A3,A3+,A4

ISO B-series sizes (B0...B9)

B2,B3,B4

Media thickness

0.08 - 1.5 mm

Roll top margin

3 mm

Ports & interfaces

Wi-Fi

N

Ethernet interface type

Gigabit Ethernet

Ethernet LAN

Y

USB port

Y

USB connector

USB Type-B

USB 2.0 ports quantity

1

Ethernet LAN data rates

10,100,1000 Mbit/s

RJ-45 ports quantity

1

Performance

Product colour

White

Built-in display

Y

Display diagonal

6.81 cm (2.68")

Internal memory

1024 MB

Sound pressure level (printing)

50 dB

Country of origin

China

Power

Power consumption (standby)

3 W

Power consumption (typical)

61 W

Power consumption (off)

0.5 W

System requirements

Windows operating systems supported

Windows 10,Windows 7,Windows 7 x64,Windows 8,Windows 8 x64,Windows 8.1,Windows Vista,Windows Vista x64,Windows XP

Mac operating systems supported

Mac OS X 10.5 Leopard

Linux operating systems supported

Y

Weight & dimensions

Width

1405 mm

Depth

974 mm

Height

1128 mm

Weight

118 kg

Packaging data

Package width

1050 mm

Package depth

1775 mm

Package height

815 mm

Package weight

999 kg

Cartridge(s) included

Y

Drivers included

Y

Manual

Y

Quick start guide

Y

Logistics data

Quantity per pack

1 pc(s)
