Dfx-9000 - Printer - Dot Matrix - A3 - USB/ Parallel / Serial

Introduction

The heavy duty dot matrix printer you can rely on
The Epson DFX-9000 is the fastest 9-pin heavy duty dot matrix printer in its class. Built to bring your business speed and reliability, it gives you the power to handle the most demanding workloads quickly and at exceptional value.

Built for demanding workloads, always ready for action
Working at high speeds
Take advantage of the fastest 9-pin heavy duty dot matrix printer in its class. With a 1,550cps print speed, the Epson DFX-9000 will deliver exceptional performance in all data processing and drafting tasks.

Working reliably
You can rely on the ongoing support of a print volume of 133 million lines MVBF*, an MTBF** of 20,000 power on hours and a 15 million characters ribbon life. Durability that keeps your business working.

Working in any environment
You can integrate the Epson DFX-9000 with existing equipment, using standard USB, Parallel and Serial interfaces (optional network, twinax, coax).

Working for your business
Utilise extensive paper handling solutions to deal with a wide range of commercial, industrial and logistic printing tasks.

Print up to 10 part forms on paper from 76.2 to 406.4mm wide. And extend your printing capabilities with the optional perforation cutter.

Key Features:
- Prints up to 10 part forms (1 original + 9 copies).
- Long ribbon life of 15 million characters.
- Standard USB, Serial and Parallel interfaces (optional network, twinax, coax).
- Flexible paper handling with two tractors as standard.
- Optional perforation cutter for automatic job separation, or for remote switching between paper sources.

Printing

Maximum resolution

240 x 144 DPI

Maximum printing width (columns)

136

Colour

N

Maximum print speed

1550 cps

Maximum print speed (draft)

1320 cps

Maximum print speed (LQ)

330 cps

Character pitch

10,12 cpi

Maximum number of copies

10 copies

Built-in barcodes

Code 39,POSTNET,UPC-A,UPC-E

Paper handling

Maximum print size

A4 (210 x 297 mm)

Paper tray media types

Labels

Features

Buffer size

128 KB

Sound pressure level (printing)

58 dB

Page description languages

ESC P,PPDS

Country of origin

Japan

Ports & interfaces

Standard interfaces

Parallel, RS-232, USB 2.0

Optional connectivity

Ethernet

Endurance

Print head

9-pin

Print direction

Bi-directional

Print head life

200 million characters

Ribbon life (black, draft)

15 million characters

Mean time between failures (MTBF)

20000 h

Power

Power consumption (typical)

185 W

Power consumption (standby)

75 W

Operational conditions

Operating temperature (T-T)

5 - 35 °C

Operating relative humidity (H-H)

10 - 80%

System requirements

Windows operating systems supported

Windows 2000,Windows 7,Windows 8,Windows 98,Windows XP

Bundled software

Epson Status Monitor

Weight & dimensions

Width

700 mm

Depth

378 mm

Height

363 mm

Weight

34 kg

Packaging data

Quantity per pack

1 pc(s)

Package width

485 mm

Package depth

840 mm

Package height

505 mm

Package weight

35.5 g

Other features

Connectivity technology

Wired

Print technology

Dot matrix

Needles

36 (4 x 9)

Logistics data

Products per pallet

4 pc(s)

Pallet gross width

120 cm

Pallet gross height

100 cm

Products per pallet layer

1 pc(s)

Products per pallet layer (UK)

2 pc(s)

Products per pallet (UK)

8 pc(s)

Pallet length (UK)

120 cm

Pallet width (UK)

100 cm

Pallet height (UK)

2.1 m
