Ultra-slim Double Arm Flat Screen Wall Mount With Tilt And Swivel (bt8221)

Introduction

Designed to mount large screens up to 65", this ultra-slim double arm wall mount features a tilting interface and three swivel points, allowing quick and easy repositioning of screens as required - whether folded flat to the wall at a depth of just 37mm or at maximum extension. Coverplates to hide fixings and integrated cable management help make this a neat and tidy mounting solution which is ideal for commercial applications as well as home installations.

Mounting

Maximum weight capacity

36 kg

Maximum screen size

165.1 cm (65")

Maximum VESA mount

600 x 400 mm

Number of displays supported

1

Mounting type

Wall

Ergonomics

Tilt angle range

-15 - 15°

Swivel angle

180°

Cable management

Y

Distance to the wall (max)

56 cm

Distance to the wall (min)

3.7 cm

Design

Product colour

Black

Weight & dimensions

Width

650 mm

Depth (max)

108.4 cm

Height

425 mm

Arm length

56 cm

Logistics data

Harmonized System (HS) code

85299097
