Single Link Hdmi And USB Extender Over Ip

Introduction

The ADDERLink XDIP is designed to improve IT scalability for small to medium businesses. Utilizing a standard 1Gb/s IP network, the XDIP enables users to extend and manage critical PCs with ultra-low latency and HD video. An intuitive API delivers remote control of the matrix and allows the XDIP to be integrated into larger systems, controlled by third party software.

Features

Type

Transmitter & receiver

Connectivity technology

Wired

Supported resolutions

The system supports video resolutions to a maximum of 1920 x 1200 @ 60Hz

Product colour

Black

Material

Metal

USB 2.0 ports quantity

4

Certification

CE, FCC

Transmitter

Transmitter video port type

HDMI

Transmitter local keyboard/mouse port type

USB

RJ-45 ports quantity (transmitter)

1

Receiver

Receiver local video port type

HDMI

Receiver local keyboard/mouse port type

USB

RJ-45 ports quantity (receiver)

1

Power

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

AC adapter output voltage

12 V

Weight & dimensions

Transmitter width

16.9 cm

Transmitter depth

12 cm

Transmitter height

3.1 cm

Transmitter weight

600 g

Packaging data

Package width

248 mm

Package depth

290 mm

Package height

55 mm

Packaging content

Cables included

Audio (3.5mm), HDMI, USB Type-A to USB Type-B

Quick installation guide

Y

Ports & interfaces

RJ-45 ports quantity

1

PC Audio in

Y

PC Audio out

Y
